Diagonal Size Class 85
Measured 84.5
Type Direct LED BLU (mini LED)
Resolution 7680 x 4320
Pixel Pitch (mm) 243.75 * 243.75 um
Active Display Area 1872(H) X 1053(V)
Brightness(Typ.) 500nit (HDR 2,000nit)
Contrast Ratio (Typ.) 1,200:1
Viewing Angle(H/V) 178/178
Response Time (G to G) 6ms(Typ.)
Display Colors 1.07B
Color Gamut 93% (DCI-P3)
Operation Hour 16/7
Haze 2%
Dynamic C/R MEGA
H-Scanning Frequency 270 HZ
V-Scanning Frequency 120 HZ
Maximum Pixel Frequency 2.376GHz
Speaker Type Built in Speaker(70W 4.2.2ch)
INPUT VIDEO HDMI 2.1 (HDMI4), HDMI 2.0 (HDMI1,2,3)
HDCP HDCP2.2
AUDIO -
USB USB 2.0 x 3
OUTPUT VIDEO N/A
AUDIO Digital Audio Out (Optcal)
Power Out N/A
USB N/A
EXTERNAL CONTROL RS232C(in) thru stereo jack, RJ45
EXTERNAL SENSOR N/A
Tuner N/A
Type Internal (OC Box)
Power Supply AC100-240V 50/60Hz
Power Consumption Max[W/h] 489.5
Typical[W/h] 390
Rating[W/h] 445
BTU(Max) 1669.2
Sleep mode 0.5
Off mode N/A
Dimension(mm) Set 1893.4 x 1083.0 x 17.4 (w/o stand)
Package 2114 x 1260 x 220
Weight (kg) Set 43.3 (w/o stand)
Package 71.7
VESA Mount 600 x 400
Protection Glass N/A
Bezel Width (Top/Side/Bot) (mm) 4 bezel-less
Operating Temperature 0?~ 40?
Humidity 10~80%
Key "8K Signage Display
Built-in MagicInfo S9, SSSP, HDR10+"
Orientation Landscape / Portrait
Special H/W "Temperature Sensor, Pivot Display, Clock Battery(168hrs Clock Keeping),
Built in Speaker(70W 4.2.2ch),Wi-Fi/BT"
S/W "Auto Source Switching & Recovery,
LFD Home UI, Button Lock, Hot key option, Plug&Play (Initial Setting)"
"Internal Player
(Embedded H/W)" Processor CA76 Quad (1.66GHz)
"On-Chip Cache
Memory" "L1 Instruction Cache : 64KB
L1 Data Cache : 64KB
L2 Cache : 256KB
L3 Cache : 2MB"
Clock Speed 1.66GHz
"Main Memory
Interface" "5GB
LPDDR4 1866MHz 128bit"
Graphics "Graphic resolution : 3840x2160
Output resolution : 7680x4320 (Scale up from graphic processing result.)"
Storage (FDM) "16GB
(5.8GB Occupied by O/S, 10.2GB Available)"
Multimedia *Video Decoder : H.264, HEVC, Motion JPEG, MVC, MPEG-1/2/4, VC1, WMV1, WMV2, H.263, VP6, AV1, VP8, VP9, RV8/9/10 *Audio Decoder : DD, DD+, LPCM, ADPCM, AAC, HE-AAC, WMA, MPEG, AC-4, G.711, OPUS, Vorbis, RealAudio6
IO Ports USB 2.0
Operating System Tizen 6.0 (VDLinux)
Safety 60065, 62368-1
EMC Class B
Environment N/A
Included "Quick Setup Guide, Warranty Card,
Power Cord, Remote Controller, Batteries"
Optional Stand In Box
Mount N/A
Specialty N/A
Media Player N/A
