2 x Socket SP5 (LGA 6096P)
AMD EPYC™ 9005 processors (Up to TDP 500W)
*TDP support by configuration.
-
E13
-
Total Slots :
24 (12-channel per CPU, 1 DIMM per CPU)
Capacity :
Total Maximum up to 3072GB
Memory Type :
DDR5 6400/5600 RDIMM/ 3DS RDIMM
Memory Size :
128GB, 96GB, 64GB, 32GB RDIMM
128GB, 96GB, 64GB, 32GB 3DS RDIMM
* Refer to www.asus.com/support for more information
-
Total 10 expansion slots
6 x PCIE Gen5 x8 or 3 x PCIE Gen5 x16 (FHFL)
2 x PCIE Gen5 x16 (FHHL)
2 x OCP3.0 Gen5 x16 (SFF)
-
24 x 2.5" hot-swap drive bays
Support 8x NVMe + 16x NVMe/SATA/SAS*
*HBA/ RAID card is required to support SAS hard drives
-
6
-
1 x Management Port
-
Aspeed AST2600 64MB
-
2 x USB 3.2 Gen1 ports
-
2 x USB 3.2 Gen1 ports
1 x Mini-DP port
1 x RJ-45 Management LAN port
1 x Debug port
-
Front Switch/LED:
1 x Power Switch w/ LED
1 x Reset Switch
1 x Location Switch w/ LED
1 x HDD Access LED
1 x Message LED
Rear Switch/LED:
1 x Power Switch w/ LED
1 x Location Switch w/LED
1 x Message LED
-
Please find the latest OS support from
https://servers.asus.com/support/os
-
On-Board ASMB12-iKVM for KVM-over-IP
ASUS Control Center Enterprise (Classic C)(Optional)
-
BSMI, CE, CB, RCM, FCC(Class A), ISED
-
822.16(L) x 484.65(W) x 87.3(H) mm
32.37(L) x 19.08(W) x 3.44(H) inch
-
2U
-
Net Weight : 17.82KG
Gross Weight : 21.34KG
-
1+1 Redundant 80 PLUS 3200W Titanium PSU
1+1 Redundant 2700W Titanium PSU
Rating:
100-120V~/220-240V~, 16A (x2), 50/60Hz
100-127V~/220-240V~, 12A/16A (x2), 50-60Hz
-
Operation temperature: 10? ~ 35?
Non operation temperature: -40? ~ 60?
Non operation humidity: 20% ~ 90% (Non condensing)
-
Security:
Dual BMC Module (default)
TPM Module (MUST bundle with ASUS server while placing order if required.)
Accessory:
2U Front Bezel
1.5U Height Full Extension Ball bearing Type Rail Kit
Cable arm (Please consult sales if required.)
-
*SAS support only from SAS HBA/RAID Card
-
2 x 2U EVAC Heatsink
-
Motherboard: 90SB0D10-M1XBN0
Front Panel Board: 90SC0SQ0-M0XBN1
Switch Board: 90SC0TK0-M0XBN1
Backplane: 90SC0TL0-M0XBN1
Riser Card 2-Slot (Slot1/2 or 3/4): 90SC0SL0-M0XBN1
Riser Card 2-Slot (Slot 5/6): 90SC0SM0-M0XBN1
Riser Card 1-Slot (Slot 7 or 9): 90SC0SP0-M0XBN1
DC-SCM Board: 90SC0SI0-M2XBN1
Fan Board: 90SC0SU0-M0XBN1
SATA/SAS Cable (BAY1-8): 90SKS000-MPHAN0
SATA/SAS Cable (BAY9-16): 90SKS000-MPDAN0
NVMe Cable (BAY1-6 or BAY7-12): 90SKS000-MPIAN0
NVMe Cable (BAY13-18): 90SKS000-MPKAN0
NVMe Cable (BAY19-24): 90SKS000-MPJAN0
2.5" HDD Tray: 90SKH000-MPPBN0
2U CPU EVAC HS: 90SKS000-MPZAN0
PSU CRPS 3200W Titanium//DELTA: 90SKS000-MMCBN0
PSU CRPS 2700W Titanium//DELTA: 90SKS000-MM2BN0
1.5U Full Extension Slide Rail: 90SKR000-M07AN0
R2P-B Cable Arm: 90SKS000-M23AN0
