| PERFORMANCE |
| Processor | Intel® Core Ultra 7 265, 20C (8P + 12E) / 20T, Max Turbo up to 5.3GHz, 30MB Intel Smart Cache |
| AI PC Category | |
| Graphics | Integrated Intel® Graphics |
| Chipset | Intel® B860 Chipset |
| Memory | 1x 16GB UDIMM DDR5-5600 |
| Memory Slots | Two DDR5 UDIMM slots, dual-channel capable |
| Max Memory | Up to 64GB DDR5-5600 |
| Storage | 1TB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 |
| Max Storage Support | - Up to three drives, 1x 3.5" HDD + 2x M.2 SSD
• 3.5" HDD up to 2TB
• M.2 SSD up to 1TB each
- For installing HDD storage, 3.5'' HDD screw and grommet kit is needed.
|
| Card Reader | 3-in-1 Card Reader |
| Optical | 9.0mm DVD±RW |
| Audio Chip | - High Definition (HD) Audio, Realtek® ALC623-CG codec
- 24-bit DAC supports 44.1K/48K/96K sample rate, 2 channel DAC supports 16/20/24-bit PCM format for independent two stereo channel or 2.1 audio playback
- 24-bit ADC supports 44.1K/48K/96K sample rate, 2 channel ADC supports 16/20/24-bit PCM format for independent two stereo channel audio inputs
|
| Speakers | 1Wx1 |
| Power Supply | 260W 90% |
| DESIGN |
| Keyboard | USB, Calliope, Black, Czech / Slovakian |
| Mouse | USB Calliope Mouse, Black |
| Expansion Slots | - One PCIe® 4.0 x16, low-profile, length ? 155mm, height ? 70mm
- One PCIe® 3.0 x1, low-profile, length ? 155mm, height ? 70mm
- Three M.2 slots (one for WLAN, two for SSD)
|
| Case Color | Raven Black |
| Stand | None |
| Pen | Pen Not Supported |
| Form Factor | SFF (8.2L) |
| Dimensions (WxDxH) | 92.5 x 291.7 x 339.5 mm (3.6 x 11.5 x 13.4 inches) |
| Weight | Around 4.62 kg (10.19 lbs.) |
| CONNECTIVITY |
| WLAN + Bluetooth | Intel® Wi-Fi® 6 AX203, 802.11ax 2x2 + BT5.2 |
| WWAN | Non-WWAN |
| Ethernet | Integrated 100/1000M |
| Front Ports | - 1x USB-C® (USB 5Gbps / USB 3.2 Gen 1), with 15W charging
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1)
- 1x headphone / microphone combo jack (3.5mm)
- 1x microphone (3.5mm)
|
| Rear Ports | - 2x USB-A (Hi-Speed USB / USB 2.0)
- 2x USB-A (USB 5Gbps / USB 3.2 Gen 1), one supports Smart Power On
- 1x HDMI® 2.1 TMDS
- 1x DisplayPort™ 1.4
- 1x Ethernet (RJ-45)
- 1x line-out (3.5mm)
|
| Optional Rear Ports (configured) | None |
| Monitor Cable | None |
| SECURITY & PRIVACY |
| Security Chip | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Physical Locks | - Kensington® Security Slot™, 3 x 7 mm
- Padlock Loop
|
| Smart Cable Clip | None |
| Chassis Intrusion Switch | Chassis Intrusion Switch |
| Additional Security | None |
| MANAGEABILITY |
| System Management | Non-vPro® |
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | 3Y Onsite upgrade from 1Y Courier/Carry-in (CPN) |
| CERTIFICATIONS |
| Green Certifications | - ENERGY STAR® 9.0
- RoHS / WEEE / REACH
|
| Other Certifications | - |
| SOFTWARE |
| Operating System | Windows® 11 Pro, Czech / Slovak / English |
| Bundled Software | None |
| ACCESSORIES |
| Bundled Accessories | 3.5" HDD Screw and Grommet Kit |
| MODEL INFORMATION |
| Model | 13DM001VCK |
| Machine Type | 13DM |
| Region | EET |
| Country/Region | Czech, Slovakia |
| TopSeller | Yes |
| EAN / UPC / JAN | 0199272229421 |
| Announce Date | 2025-09-09 |
| End of Support | 2032-04-09 |
